SLV W 1 SMD 073 23 G

Headers, Male Pins Overview

The SLV W 1 SMD 073 23 G is a single-row expanded insulator connector header designed for surface mount technology. It features 23 positions with a 0.050-inch (1.27 mm) pitch. The component utilizes gold-plated contacts to ensure reliable electrical performance in board-to-board and wire-to-board applications.

Headers, Male Pins Feature Summary

• Surface mount design for automated PCB assembly
• Single row configuration with expanded insulator
• Gold-plated contact surfaces for durability

Headers, Male Pins Applications

• Board-to-board interconnections
• Wire-to-board connections
• General electronic equipment internal wiring

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the manufacturer's current datasheet to confirm pin count and plating specifications. Ensure compatibility with standard reflow soldering profiles. Confirm that the selected variant matches the required 23-position layout for your circuit design.

Headers, Male Pins Selection Notes

Select this component when a single-row, surface-mount header with a 1.27 mm pitch is required. Consider the expanded insulator design for improved mechanical stability during assembly. Evaluate the gold plating option if high corrosion resistance and low contact resistance are critical for the application environment.

Headers, Male Pins Part Context

This part belongs to Fischer Elektronik's SLV series of PCB connectors. The series offers various configurations including different row counts and pitch options. The 'SMD' designation indicates suitability for surface mount processes, while the numeric suffixes define specific physical dimensions and contact arrangements within the product family.

Headers, Male Pins Replacement Considerations

Consult Fischer Elektronik documentation for direct substitutes with identical pitch and contact count. Verify mechanical footprint compatibility before replacing with generic equivalents.
