SMS1105PGC

$1.24

Description：LED GREEN CLEAR 2PLCC SMD R/A
Series：-
Mfr：Bivar Inc.
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:a5ec53778b0d Category: LED Indication - Discrete Brand: Bivar Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

SMS1105PGC is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists Bivar Inc.. Its product description is LED GREEN CLEAR 2PLCC SMD R/A. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for SMS1105PGC

Description：LED GREEN CLEAR 2PLCC SMD R/A
Series：-
Mfr：Bivar Inc.
Package：Tape & Reel (TR),Cut Tape (CT)
Color：Green
Configuration：Standard
Lens Color：Colorless
Lens Transparency：Clear
Millicandela Rating：2100mcd
Lens Style：Rectangle with Flat Top
Lens Size：2.50mm x 0.80mm
Voltage - Forward (Vf) (Typ)：3.1V
Current - Test：20mA
Viewing Angle：120°
Mounting Type：Surface Mount, Right Angle
Wavelength - Dominant：529nm
Wavelength - Peak：-
Features：-
Package / Case：2-SMD, J-Lead
Supplier Device Package：2-PLCC
Size / Dimension：2.80mm L x 1.20mm W
Height (Max)：0.80mm
Grade：-
Qualification：-

LED Indication - Discrete datasheet and documents for SMS1105PGC

SMS1105PGC

LED Indication - Discrete Overview

The SMS1105PGC is a surface-mount LED from Bivar Inc., housed in a PLCC-2 package. It emits pure green light at a wavelength of 529 nm with a viewing angle of 120 degrees. The component operates with a forward current of 20 mA and a forward voltage of 3.1 V, consuming 80 mW of power. Its dimensions are 2.5 mm in length, 0.8 mm in width, and 1.2 mm in height. The device functions within a temperature range of -30°C to +85°C.

LED Indication - Discrete Feature Summary

Side-view emission configuration within an industry-standard PLCC-2 package
Low profile design suitable for space-constrained applications
High luminous intensity output with wide viewing angles

LED Indication - Discrete Applications

Electronic equipment status indication
Control panel indicator lights
Consumer electronics display modules

LED Indication - Discrete Procurement Notes

Verify the specific datasheet version for the SMS1105PGC to confirm RoHS compliance details and exact thermal characteristics. Ensure that the ordering suffix matches the required color and packaging specifications. Cross-reference the manufacturer's official documentation for any updates on end-of-life status or recommended replacement components before finalizing procurement plans.

LED Indication - Discrete Selection Notes

Select this component when a side-view indicator is required in a standard PLCC-2 footprint. The 120-degree viewing angle provides broad visibility compared to narrow-beam alternatives. Consider the 3.1 V forward voltage drop for circuit design compatibility. Evaluate the low-profile physical dimensions against available board space constraints during the selection process.

LED Indication - Discrete Part Context

The SMS1105 series represents Bivar's discrete surface-mount LED offerings designed for general-purpose indication. These LEDs utilize a plastic leaded chip carrier package to facilitate automated assembly. The series includes various colors, with the PGC variant specifically providing pure green emission characteristics for visual signaling applications.
