SRU6013-330Y

Fixed Inductors Overview

The Bourns SRU6013-330Y is a shielded surface-mount power inductor from the SRU6013 series, featuring a ferrite core and wirewound construction. It offers an inductance of 33 µH with a tolerance of ±30%. The component supports a maximum DC current of 780 mA and has a maximum DC resistance of 500 mΩ. Operating within a temperature range of -40°C to +125°C, it meets AEC-Q200 automotive qualification standards. Key electrical parameters include a minimum Q factor of 10 at 2.52 MHz and a self-resonant frequency of 18 MHz.

Fixed Inductors Feature Summary

• Shielded SMD power inductor design for reduced electromagnetic interference
• AEC-Q200 qualified for automotive electronic applications
• Ferrite core construction with standard tin terminal finish

Fixed Inductors Applications

• Automotive power supply circuits
• DC-DC converter modules
• Power delivery systems requiring compact shielding

Fixed Inductors Procurement Notes

Verify the specific suffix 'Y' against the manufacturer's official documentation to confirm packaging configuration and tape-and-reel specifications. Ensure that the AEC-Q200 automotive qualification status aligns with your project's reliability requirements. Cross-reference the 780 mA current rating and 500 mΩ resistance values with the latest datasheet to account for any potential revisions or updates to the component specifications.

Fixed Inductors Selection Notes

Select this component when a shielded inductor with AEC-Q200 certification is required for space-constrained automotive designs. The 33 µH value suits moderate current applications where low DC resistance is beneficial. Consider the 1.4 mm height profile for board layout constraints. Compare performance against non-shielded alternatives if EMI mitigation is not a primary design driver.

Fixed Inductors Part Context

The SRU6013-330Y belongs to the SRU6013 series of shielded SMD power inductors manufactured by Bourns Inc. This series is designed for high-efficiency power conversion applications. The model number indicates a 33 µH inductance value. The series utilizes a ferrite core and wirewound technology to provide stable performance across a wide temperature range.

Fixed Inductors Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source data. Consult the manufacturer's official substitution guide or contact technical support for verified cross-reference information.
