SST39SF040-70-4C-PHE

$3.39

Description：IC FLASH 4MBIT PARALLEL 32DIP
Series：SST39 MPF™
Mfr：Microchip Technology
Package：Tube

SKU:4d3a9e3553a9 Category: Memory IC Brand: Microchip Technology

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

SST39SF040-70-4C-PHE is listed in the Memory IC range at ChipApex. The manufacturer field lists Microchip Technology. Its product description is IC FLASH 4MBIT PARALLEL 32DIP. Review the specifications below when checking this part for your BOM.

Memory IC specifications for SST39SF040-70-4C-PHE

Description：IC FLASH 4MBIT PARALLEL 32DIP
Series：SST39 MPF™
Mfr：Microchip Technology
Package：Tube
Memory Type：Non-Volatile
Memory Format：FLASH
Technology：FLASH
Memory Size：4Mbit
Memory Organization：512K x 8
Memory Interface：Parallel
Clock Frequency：-
Write Cycle Time - Word, Page：20µs
Voltage - Supply：4.5V ~ 5.5V
Operating Temperature：0°C ~ 70°C (TA)
Mounting Type：Through Hole
Package / Case：32-DIP (0.600", 15.24mm)
Supplier Device Package：32-PDIP
Access Time：70 ns
Grade：-
Qualification：-

Memory IC datasheet and documents for SST39SF040-70-4C-PHE

SST39SF040-70-4C-PHE

Memory IC Overview

The SST39SF040-70-4C-PHE is a 4-Mbit (512K x 8) Multi-Purpose Flash manufactured using SuperFlash technology. It operates on a single 4.5V to 5.5V supply and features a 70 ns access time. The device utilizes a parallel interface with TTL-compatible I/Os and includes internal VPP generation for write operations. It supports uniform 4-Kbyte sector erasure, byte programming, and hardware/software data protection schemes.

Memory IC Feature Summary

SuperFlash Technology: Split-gate cell design ensures superior reliability and manufacturability compared to alternate approaches.
Sector Erase Capability: Uniform 4-Kbyte sectors allow for efficient memory management and updates.
Data Protection: Includes hardware noise/glitch protection and JEDEC-approved software data protection sequences.
Internal VPP Generation: Eliminates the need for external high-voltage supplies during program and erase cycles.

Memory IC Applications

Code storage in embedded systems requiring direct execution from flash.
Configuration memory for hardware devices needing frequent updates.
Data storage applications requiring non-volatile retention of user settings.

Memory IC Procurement Notes

Verify the package type matches the 'PHE' suffix designation against official Microchip documentation. Confirm the temperature range corresponds to the 'C' commercial rating. Ensure compatibility with the required voltage levels and timing specifications for the target system design.

Memory IC Selection Notes

Select this component for applications requiring 4-Mbit capacity with a 70 ns access speed. It is suitable for systems operating within the 4.5V to 5.5V range. Consider the PLCC or PDIP package options based on board space and assembly requirements. Verify that the 4-Kbyte sector size aligns with the application's erase granularity needs.

Memory IC Part Context

This part belongs to the SST39SF010A/020A/040 series of CMOS Multi-Purpose Flash memories. These devices are designed for economical updating of program, configuration, or data memory. They offer low power consumption and fast erase/program times, making them ideal for various industrial and consumer electronics applications.
