STM32F765IGK6TR

Microcontrollers Overview

The STM32F765IGK6TR is a high-performance microcontroller based on the Arm Cortex-M7 core, operating at up to 216 MHz. It features 1 Mbyte of Flash memory and 512 Kbytes of SRAM, including Data TCM RAM and Instruction TCM RAM. The device integrates an ART Accelerator, L1 cache, and a double-precision FPU. Key peripherals include three 12-bit ADCs, two DACs, multiple communication interfaces such as USB OTG, Ethernet, and SDMMC, alongside a Chrom-ART Accelerator and LCD-TFT controller. It operates within a supply voltage range of 1.7V to 3.6V and supports industrial temperatures from -40°C to 85°C.

Microcontrollers Feature Summary

• High-performance execution enabled by the Arm Cortex-M7 core with ART Accelerator and L1 cache for zero-wait-state operation.
• Integrated graphics acceleration via Chrom-ART Accelerator and hardware JPEG codec for efficient image processing.
• Flexible external memory controller supporting SDRAM, PSRAM, NOR, and NAND memories for expanded system capabilities.
• Advanced connectivity options including dual USB OTG, Ethernet MAC, and multiple serial audio interfaces (SAI/I2S).

Microcontrollers Applications

• Industrial applications requiring real-time control and DSP capabilities
• Medical devices utilizing high-resolution displays and precise data conversion
• Infotainment systems leveraging graphics acceleration and multimedia codecs
• Smart home gateways with extensive connectivity requirements

Microcontrollers Procurement Notes

Verify the specific suffix 'K6' against official STMicroelectronics documentation to confirm package details and pinout compatibility. Ensure that the tape and reel configuration matches automated assembly requirements. Cross-reference the full part number with the latest datasheet revision to validate electrical characteristics and operational temperature ranges before finalizing procurement specifications.

Microcontrollers Selection Notes

Select this component when application demands exceed standard Cortex-M4 performance levels. The inclusion of double-precision FPU and dedicated DMA controllers makes it suitable for complex signal processing tasks. Consider the available I/O count and peripheral set relative to system interface needs. Evaluate power consumption profiles in active and low-power modes against battery or thermal constraints.

Microcontrollers Part Context

This part belongs to the STM32F765xx series within the broader STM32F7 family. It shares architectural similarities with variants like the STM32F767 and STM32F769 but differs in memory capacity and specific peripheral availability. The series targets high-end embedded applications requiring significant computational power and rich connectivity options.

Microcontrollers Replacement Considerations

Direct substitutes within the same package and pinout may include other STM32F765xx variants with compatible memory sizes. Verify functional equivalence regarding peripheral sets and clock speeds. Consult official cross-reference guides for alternative packages if form factor changes are permissible.
