STPS10H100SFY

$0.91

Description：DIODE ARR SCHOTT 100V 10A TO277A
Series：-

SKU:3de3c51bbb36 Category: Diode Arrays Brand: STMicroelectronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

STPS10H100SFY is listed in the Diode Arrays range at ChipApex. The manufacturer field lists STMicroelectronics. Its product description is DIODE ARR SCHOTT 100V 10A TO277A. Review the specifications below when checking this part for your BOM.

Diode Arrays specifications for STPS10H100SFY

Description：DIODE ARR SCHOTT 100V 10A TO277A
Series：-
Mfr：STMicroelectronics
Package：Tape & Reel (TR),Cut Tape (CT)
Diode Configuration：-
Technology：Schottky
Voltage - DC Reverse (Vr) (Max)：100 V
Current - Average Rectified (Io) (per Diode)：10A
Voltage - Forward (Vf) (Max) @ If：845 mV @ 10 A
Speed：Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr)：-
Current - Reverse Leakage @ Vr：8 µA @ 100 V
Operating Temperature - Junction：-40°C ~ 175°C
Mounting Type：Surface Mount
Package / Case：TO-277, 3-PowerDFN
Supplier Device Package：TO-277A (SMPC)
Grade：Automotive
Qualification：AEC-Q101

Diode Arrays datasheet and documents for STPS10H100SFY

STPS10H100SFY

Diode Arrays Overview

The STPS10H100SFY is a 10 A, 100 V power Schottky rectifier designed for automotive applications. Packaged in PSMC (TO-277A), it features a maximum junction temperature of 175 °C and typical forward voltage of 0.615 V at 10 A. It supports a repetitive peak reverse voltage of 100 V and a non-repetitive surge current of 230 A. The device offers low leakage current and specified avalanche capability.

Diode Arrays Feature Summary

AEC-Q101 qualified for automotive reliability
Negligible switching losses due to Schottky barrier
Wettable flanks enable automatic visual inspection
PPAP capable with ECOPACK®2 compliance

Diode Arrays Applications

DC / DC converter
Reverse polarity protection
Freewheeling diode
Switching diode

Diode Arrays Procurement Notes

Verify the specific ordering code matches the required delivery mode, as the standard configuration utilizes tape and reel packaging. Confirm that the component meets all necessary environmental standards and quality requirements for your intended application before finalizing procurement decisions.

Diode Arrays Selection Notes

Select this component when high junction temperature operation up to 175 °C is required. It is suitable for designs needing low leakage current and avalanche capability within a compact PSMC package. Ensure thermal management strategies align with the specified thermal resistance parameters for optimal performance.

Diode Arrays Part Context

This part belongs to STMicroelectronics' automotive-grade Schottky rectifier series. It is engineered to provide robust performance in confined environments where high operating temperatures are prevalent. The device integrates advanced trench technology to minimize conduction and switching losses effectively.

Diode Arrays Replacement Considerations

Check datasheets for alternative parts offering similar voltage and current ratings. Verify package compatibility and thermal characteristics to ensure seamless integration without redesigning the PCB layout or cooling infrastructure.
