SXR151M035ST

SXR151M035ST is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists Cornell Dubilier Knowles. Its product description is CAP ALUM 150UF 20% 35V RADIAL TH. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for SXR151M035ST

• Description：CAP ALUM 150UF 20% 35V RADIAL TH
• Series：SXR
• Mfr：Cornell Dubilier Knowles
• Package：Bulk
• Capacitance：150 µF
• Tolerance：±20%
• Voltage - Rated：35 V
• ESR (Equivalent Series Resistance)：1.06Ohm @ 120Hz
• Lifetime @ Temp.：4000 Hrs @ 105°C
• Operating Temperature：-40°C ~ 105°C
• Polarization：Polar
• Ratings：-
• Applications：General Purpose
• Ripple Current @ Low Frequency：275 mA @ 120 Hz
• Ripple Current @ High Frequency：550 mA @ 100 kHz
• Lead Spacing：0.197" (5.00mm)
• Size / Dimension：0.394" Dia (10.00mm)
• Height - Seated (Max)：0.472" (12.00mm)
• Surface Mount Land Size：-
• Mounting Type：Through Hole
• Package / Case：Radial, Can

Aluminum Electrolytic Capacitors datasheet and documents for SXR151M035ST
