THM 60-2422WI

THM 60-2422WI is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Traco Power. Its product description is 60W MEDICAL DC/DC CONVERTER ISOL. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for THM 60-2422WI

• Description：60W MEDICAL DC/DC CONVERTER ISOL
• Series：THM 60WI (60W)
• Mfr：Traco Power
• Package：Box
• Type：Isolated Module
• Number of Outputs：2
• Voltage - Input (Min)：9V
• Voltage - Input (Max)：36V
• Voltage - Output 1：12V
• Voltage - Output 2：-12V
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：2.5A, 2.5A
• Power (Watts)：60 W
• Voltage - Isolation：5 kV
• Applications：ITE (Commercial), Medical
• Features：Adjustable Output, Remote On/Off
• Operating Temperature：-40°C ~ 70°C (With Derating)
• Efficiency：89%
• Mounting Type：Through Hole
• Package / Case：Quarter Brick
• Size / Dimension：2.28" L x 1.45" W x 0.50" H (57.9mm x 36.8mm x 12.7mm)
• Supplier Device Package：Quarter Brick
• Control Features：-
• Approval Agency：CB, cURus
• Standard Number：60601-1; 62368-1
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for THM 60-2422WI
