TL1270F160BLQAT

TL1270F160BLQAT is listed in the Tactile Switches range at ChipApex. The manufacturer field lists E-Switch. Its product description is SWITCH TACTILE SPST-NO 0.05A 12V. Review the specifications below when checking this part for your BOM.

Tactile Switches specifications for TL1270F160BLQAT

• Description：SWITCH TACTILE SPST-NO 0.05A 12V
• Series：TL1270
• Mfr：E-Switch
• Package：Tape & Reel (TR),Cut Tape (CT)
• Circuit：SPST-NO
• Switch Function：Off-Mom
• Contact Rating @ Voltage：0.05A @ 12VDC
• Actuator Type：Round Button
• Mounting Type：Through Hole, Right Angle
• Actuator Height off PCB, Vertical：-
• Actuator Length, Right Angle：5.62mm
• Actuator Orientation：Side Actuated
• Termination Style：PC Pin
• Outline：4.50mm x 4.95mm
• Illumination：Illuminated
• Illumination Type, Color：LED, Blue
• Illumination Voltage (Nominal)：3.6 VDC
• Operating Force：160gf
• Ingress Protection：-
• Features：-
• Operating Temperature：-40°C ~ 85°C

Tactile Switches datasheet and documents for TL1270F160BLQAT
