TM266DVA2

Drivers, Receivers, Transceivers Overview

The TM266DVA2 is an IEEE 1394B Ethernet transceiver module manufactured by iNRCORE, LLC. It operates at a data rate of 265.625 Mbps and supports a supply voltage range from 3.13 V to 3.47 V, with a maximum power dissipation of 500 mW. The component features one transmitter and one receiver, housed in a 28-DIP Module package suitable for through-hole mounting. It functions within an operating temperature range of -55°C to +125°C and exhibits moisture sensitivity level 3.

Drivers, Receivers, Transceivers Feature Summary

• Supports IEEE 1394B protocol standards for high-speed serial communication
• Integrates single-channel transmission and reception capabilities within a unified module
• Designed for robust operation across extended industrial temperature ranges

Drivers, Receivers, Transceivers Applications

• Industrial automation control systems requiring reliable serial connectivity
• Test and measurement equipment interfaces
• Embedded networking solutions in harsh environmental conditions

Drivers, Receivers, Transceivers Procurement Notes

Verify the specific datasheet version and RoHS compliance status prior to procurement, as documentation indicates potential variations in regulatory adherence. Confirm that the 28-DIP Module package aligns with the target PCB footprint and thermal management requirements. Ensure that the operating voltage specifications match the system power rails to prevent malfunction or damage during integration.

Drivers, Receivers, Transceivers Selection Notes

Select this component when a dedicated IEEE 1394B transceiver solution is required for through-hole assembly. Consider the wide operating temperature range and low supply current characteristics for energy-constrained applications. Evaluate the 500 mW power dissipation limit against the available thermal relief on the printed circuit board to ensure stable long-term performance under continuous load conditions.

Drivers, Receivers, Transceivers Part Context

This part belongs to the Copperhead series of interface components from iNRCORE, LLC. It serves as a specialized communication interface chip designed to bridge digital devices using FireWire standards. The module format simplifies integration into larger systems compared to discrete component implementations, providing a compact solution for networked device interconnectivity.

Drivers, Receivers, Transceivers Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with existing circuit designs before attempting to source alternative components from other manufacturers.
