TPL710F10-3TR

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Overview

The TPL710F10-3TR is a fixed-output linear voltage regulator manufactured by 3PEAK. It provides a stable 1V output with a maximum load current of 200mA. The device operates from an input voltage range up to 6V and features a typical dropout voltage of 0.17V at full load. Key electrical specifications include a quiescent current of 30µA and power supply rejection ratios of 55dB at 100Hz and 53dB at 1MHz. It is housed in a compact 4-XDFN package with an exposed pad, suitable for surface-mount assembly.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Feature Summary

• Provides a fixed 1V output voltage for precise rail generation
• Integrates comprehensive protection including overcurrent, thermal shutdown, and UVLO
• Features low quiescent current for efficient battery-powered operation
• Offers high power supply rejection ratio across frequency ranges

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Applications

• Portable consumer electronics requiring stable low-voltage rails
• Battery-operated devices needing extended runtime efficiency
• Embedded systems utilizing 3PEAK PMIC families
• IoT modules with strict space and power constraints

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Procurement Notes

Verify the specific suffix '3TR' against official 3PEAK documentation to confirm tape-and-reel packaging quantities and orientation. Ensure the ordering part number matches the exact output voltage variant required, as family members differ only by output setting. Cross-reference the manufacturer's latest datasheet for any updates on RoHS compliance or moisture sensitivity levels prior to procurement.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Selection Notes

Select this component when a fixed 1V output is required within a 6V input window. Consider the 200mA current limit for load requirements and the 4-XDFN package for footprint constraints. Evaluate the 30µA quiescent current against system sleep mode requirements. Compare PSRR performance if noise-sensitive analog sections are present on the same rail.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Part Context

This part belongs to the TPL710 series of low-dropout regulators from 3PEAK. The series offers various fixed output voltages sharing identical pinouts and protection features. The TPL710F10 specifically denotes the 1V output variant. These regulators are designed for applications requiring small form factors and high reliability in portable and industrial environments.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Replacement Considerations

Direct substitutes within the TPL710 family include other output voltage variants such as TPL710F18 or TPL710F25, provided the circuit design accommodates the different voltage level. Verify that alternative LDOs from other manufacturers match the 200mA current rating, 6V max input, and 4-XDFN package dimensions for mechanical compatibility.
