UPJ1H221MPD1TD

UPJ1H221MPD1TD is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists Nichicon. Its product description is CAP ALUM 220UF 20% 50V RADIAL TH. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for UPJ1H221MPD1TD

• Description：CAP ALUM 220UF 20% 50V RADIAL TH
• Series：UPJ
• Mfr：Nichicon
• Package：Cut Tape (CT),Tape & Box (TB)
• Capacitance：220 µF
• Tolerance：±20%
• Voltage - Rated：50 V
• ESR (Equivalent Series Resistance)：-
• Lifetime @ Temp.：5000 Hrs @ 105°C
• Operating Temperature：-55°C ~ 105°C
• Polarization：Polar
• Ratings：-
• Applications：General Purpose
• Ripple Current @ Low Frequency：760 mA @ 120 Hz
• Ripple Current @ High Frequency：1.04 A @ 10 kHz
• Lead Spacing：0.197" (5.00mm)
• Size / Dimension：0.394" Dia (10.00mm)
• Height - Seated (Max)：1.063" (27.00mm)
• Surface Mount Land Size：-
• Mounting Type：Through Hole
• Package / Case：Radial, Can
• Impedance：98 mOhms

Aluminum Electrolytic Capacitors datasheet and documents for UPJ1H221MPD1TD
