URD24D15-10W

URD24D15-10W is listed in the DC DC Converters range at ChipApex. The manufacturer field lists HenLv Power. Its product description is DC DC CONVERTER +/-15V 10W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for URD24D15-10W

• Description：DC DC CONVERTER +/-15V 10W
• Series：-
• Mfr：HenLv Power
• Package：Bulk
• Type：Isolated Module
• Number of Outputs：2
• Voltage - Input (Min)：18V
• Voltage - Input (Max)：72V
• Voltage - Output 1：15V
• Voltage - Output 2：-15V
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：330mA
• Power (Watts)：10 W
• Voltage - Isolation：3 kV
• Applications：ITE (Commercial)
• Features：-
• Operating Temperature：-40°C ~ 85°C (With Derating)
• Efficiency：82%
• Mounting Type：Through Hole
• Package / Case：5-DIP Module
• Size / Dimension：2.00" L x 1.00" W x 0.41" H (50.8mm x 25.4mm x 10.5mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-
