VCD40-D24-S15

VCD40-D24-S15 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists CUI Inc.. Its product description is DC DC CONVERTER 15V 40W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for VCD40-D24-S15

• Description：DC DC CONVERTER 15V 40W
• Series：VCD40 (40W)
• Mfr：CUI Inc.
• Package：Tube
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：18V
• Voltage - Input (Max)：36V
• Voltage - Output 1：15V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：2.666A
• Power (Watts)：40 W
• Voltage - Isolation：1.5 kV
• Applications：ITE (Commercial)
• Features：OTP, OVP, SCP
• Operating Temperature：-40°C ~ 85°C
• Efficiency：92%
• Mounting Type：Through Hole
• Package / Case：9-DIP Module
• Size / Dimension：2.00" L x 2.00" W x 0.40" H (50.8mm x 50.8mm x 10.2mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：UL
• Standard Number：60950-1
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for VCD40-D24-S15
