VS8V0UA1LAMTR

VS8V0UA1LAMTR is listed in the Tvs Diodes range at ChipApex. The manufacturer field lists Rohm Semiconductor. Its product description is TVS DIODE 8VWM 13.6VC PMDTM. Review the specifications below when checking this part for your BOM.

Tvs Diodes specifications for VS8V0UA1LAMTR

• Description：TVS DIODE 8VWM 13.6VC PMDTM
• Series：-
• Mfr：Rohm Semiconductor
• Package：Tape & Reel (TR),Cut Tape (CT)
• Type：Zener
• Bidirectional Channels：-
• Voltage - Reverse Standoff (Typ)：8V (Max)
• Voltage - Breakdown (Min)：8.89V
• Voltage - Clamping (Max) @ Ipp：13.6V
• Current - Peak Pulse (10/1000µs)：44.1A
• Power - Peak Pulse：600W
• Power Line Protection：No
• Applications：General Purpose
• Capacitance @ Frequency：-
• Operating Temperature：150°C (TJ)
• Mounting Type：Surface Mount
• Package / Case：SOD-128
• Supplier Device Package：PMDTM
• Unidirectional Channels：1
• Grade：-
• Qualification：-
