WP7083SEDK/J3

$0.14

Description：LED RED DIFFUSED T-1 3/4 T/H
Series：-
Mfr：Kingbright
Package：Bulk

SKU:eb44a986a97a Category: LED Indication - Discrete Brand: Kingbright

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

WP7083SEDK/J3 is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists Kingbright. Its product description is LED RED DIFFUSED T-1 3/4 T/H. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for WP7083SEDK/J3

Description：LED RED DIFFUSED T-1 3/4 T/H
Series：-
Mfr：Kingbright
Package：Bulk
Color：Red
Configuration：Standard
Lens Color：Orange
Lens Transparency：Diffused
Millicandela Rating：1500mcd
Lens Style：Round with Domed Top
Lens Size：5mm, T-1 3/4
Voltage - Forward (Vf) (Typ)：2.2V
Current - Test：20mA
Viewing Angle：60°
Mounting Type：Through Hole
Wavelength - Dominant：625nm
Wavelength - Peak：640nm
Features：-
Package / Case：Radial
Supplier Device Package：T-1 3/4
Size / Dimension：5.00mm Dia
Height (Max)：9.85mm
Grade：-
Qualification：-

LED Indication - Discrete datasheet and documents for WP7083SEDK/J3

WP7083SEDK/J3

LED Indication - Discrete Overview

The WP7083SEDK/J3 is a single-color red LED from Kingbright, housed in a T-1 3/4 (5mm) radial through-hole package. It features a diffused lens with a dome shape and emits light at a dominant wavelength of 625nm. The component operates with a typical forward voltage of 2.2V at a test current of 20mA. It provides an optical intensity of 900mcd with a viewing angle of 60 degrees. The unit is designed for industrial temperature ranges from -40°C to +85°C.

LED Indication - Discrete Feature Summary

Emits red light at 625nm with high intensity
Features a diffused dome lens for wide visibility
Supports standard through-hole mounting

LED Indication - Discrete Applications

Panel indicator lights
Status indication in electronic devices
Control panel signaling

LED Indication - Discrete Procurement Notes

Verify the specific suffix J3 against the manufacturer's latest datasheet to confirm lens type and binning requirements. Ensure the procurement channel provides official Kingbright documentation to validate RoHS compliance and lead times. Cross-reference the part number with distributor catalogs to confirm availability and packaging details before ordering.

LED Indication - Discrete Selection Notes

Select this component when a bright red visual signal is required in a 5mm through-hole form factor. The diffused lens offers a broad viewing angle suitable for general status indication. Consider the 2.2V forward voltage drop for circuit design and ensure the operating environment falls within the specified temperature range.

LED Indication - Discrete Part Context

This part belongs to Kingbright's standard discrete LED lineup, utilizing InGaAlP technology for red emission. The WP7083 series is widely used in consumer electronics and industrial equipment where reliable visual feedback is necessary. The T-1 3/4 package is a common industry standard for easy integration into printed circuit boards.
