XAL6030-561MEC

Description：FIXED IND 560NH 22A 3.31MOHM SM
Series：XAL60XX
Mfr：Coilcraft
Package：Strip

SKU:6433a0cae63c Category: Fixed Inductors Brand: Coilcraft

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

XAL6030-561MEC is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Coilcraft. Its product description is FIXED IND 560NH 22A 3.31MOHM SM. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for XAL6030-561MEC

Description：FIXED IND 560NH 22A 3.31MOHM SM
Series：XAL60XX
Mfr：Coilcraft
Package：Strip
Type：Molded
Material - Core：Metal Composite
Inductance：560 nH
Tolerance：±20%
Current Rating (Amps)：22 A
Current - Saturation (Isat)：29A
Shielding：Shielded
DC Resistance (DCR)：3.31mOhm Max
Q @ Freq：-
Frequency - Self Resonant：61MHz
Ratings：AEC-Q200
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.258" L x 0.250" W (6.56mm x 6.36mm)
Height - Seated (Max)：0.122" (3.10mm)
Features：-

Fixed Inductors datasheet and documents for XAL6030-561MEC

XAL6030-561MEC

Fixed Inductors Overview

The Coilcraft XAL6030-561MEC is a shielded surface-mount power inductor from the XAL6030 series, designed for automotive applications. It features a composite core and molded construction with an inductance of 560 nH and a tolerance of 20%. The component supports a maximum DC current of 17 A and reaches saturation at 24 A. Its maximum DC resistance is 8.9 mOhms, with a self-resonant frequency of 100 MHz. Operating within a temperature range of -40°C to +125°C, it meets AEC-Q200 qualification standards.

Fixed Inductors Feature Summary

AEC-Q200 qualified for automotive reliability
Shielded design minimizes electromagnetic interference
Composite core material ensures stable performance

Fixed Inductors Applications

Automotive power distribution systems
DC-DC converter output filtering
High-current point-of-load regulation

Fixed Inductors Procurement Notes

Verify the specific suffix against official Coilcraft documentation to confirm electrical characteristics and packaging options. Ensure compatibility with automated pick-and-place equipment by checking reel specifications. Confirm RoHS compliance status through the manufacturer's latest datasheet before integration into production lines.

Fixed Inductors Selection Notes

Select this component when high current handling and low impedance are critical for automotive power stages. The compact SMD footprint suits space-constrained designs. Evaluate thermal management requirements based on the 17 A continuous current rating and ambient operating conditions up to 125°C.

Fixed Inductors Part Context

This part belongs to the XAL6030 family of high-power shielded inductors. The series offers various inductance values tailored for demanding automotive environments. The XAL6030-561MEC specifically targets applications requiring robust current handling in a small form factor.
