XC53M4-8.000-F20NLDTK

Crystals Overview

The XC53M4-8.000-F20NLDTK is a surface-mount quartz crystal resonator manufactured by Suzhou Hangjing Elec&Tech Co.,Ltd. It operates at a fundamental frequency of 8.000 MHz with a load capacitance of 20 pF and an equivalent series resistance of 80 Ohms. The component utilizes a 4-SMD, No Lead package configuration. Frequency stability is rated at ±10 ppm over the operating temperature range of -10°C to +60°C. The device is RoHS compliant and lead-free, designed for precise timing applications in compact electronic circuits.

Crystals Feature Summary

• Surface-mount design for automated assembly
• Quartz-based frequency control unit
• RoHS compliant construction

Crystals Applications

• General purpose timing circuits
• Microcontroller clock sources
• Communication module oscillators

Crystals Procurement Notes

Verify manufacturer authenticity through official channels. Confirm datasheet revision matches production batch. Ensure storage conditions preserve crystal integrity. Validate RoHS compliance documentation for regulatory requirements. Check package marking accuracy against order specifications.

Crystals Selection Notes

Select based on required load capacitance matching circuit design. Consider temperature stability requirements for operational environment. Evaluate physical dimensions for PCB layout constraints. Verify frequency tolerance meets system precision needs. Assess mounting method compatibility with assembly processes.

Crystals Part Context

This component belongs to the XC53M4 series of quartz crystals from Suzhou Hangjing. The series offers various frequencies and packages. The manufacturer specializes in quartz frequency controlling units. Founded in 2014, the company focuses on R&D and production. This specific model provides stable timing for digital systems.

Crystals Replacement Considerations

XC53G2-8.000-F20NJDTK shares similar electrical characteristics but may differ in package or stability specifications. Verify pinout and mechanical dimensions before substitution. Consult official cross-reference lists for confirmed equivalents.
