XLFBB14W

LED Indication - Discrete Overview

The XLFBB14W is a blue discrete LED from SunLED, featuring a T-1 3/4 (5mm) round domed lens with clear transparency. It operates at a typical forward voltage of 3.3V and a test current of 20mA. The component emits light at a dominant wavelength of 470nm with a peak wavelength of 465nm. It provides a high luminous intensity of 2990mcd and offers a viewing angle of 15 degrees. Designed for through-hole mounting, it supports an operating temperature range of -40°C to +85°C.

LED Indication - Discrete Feature Summary

• High-intensity blue illumination suitable for visible indication applications
• Standard T-1 3/4 radial package with a round domed lens design
• Wide operational temperature range for diverse environmental conditions

LED Indication - Discrete Applications

• Panel indicator lights
• Power supply status indicators
• Electronic device front panels

LED Indication - Discrete Procurement Notes

Verify the specific datasheet version for the XLFBB14W to confirm mechanical dimensions and electrical tolerances. Ensure compatibility with through-hole assembly processes. Check RoHS compliance status against regional regulations. Confirm lead availability and moisture sensitivity levels prior to storage and soldering operations.

LED Indication - Discrete Selection Notes

Select this component when high visibility in a standard 5mm radial form factor is required. The 2990mcd rating ensures bright output compared to lower-intensity alternatives. Consider the 15-degree beam angle for focused directional lighting needs rather than wide-area diffusion.

LED Indication - Discrete Part Context

This part belongs to SunLED's discrete LED lineup, specifically the T-1 3/4 series. It serves as a standard replacement for legacy 5mm LEDs in industrial and consumer electronics. The product maintains consistency with common pin spacing and mechanical profiles found in existing PCB layouts.

LED Indication - Discrete Replacement Considerations

Direct substitutes must match the 5mm radial package, 470nm blue wavelength, and similar forward voltage characteristics. Verify that alternative components support the same 20mA test current and provide comparable luminous intensity for visual equivalence.
