XLM2ACR11W

LED Indication - Discrete Overview

The XLM2ACR11W is a single-color red light-emitting diode manufactured by SunLED Corporation. It utilizes a T-1 (3mm) radial leaded package with a water-clear lens style featuring a domed top. The device emits light at a peak wavelength of 625nm and operates with a typical forward voltage of 2.2V at a test current of 20mA. It provides a millicandela rating of 2390mcd, ensuring high visibility for indication purposes while maintaining low power consumption characteristics suitable for various electronic applications.

LED Indication - Discrete Feature Summary

• Utilizes a T-1 3mm radial leaded package design for through-hole mounting
• Features a water-clear lens with a domed top for optimized light transmission
• Delivers high luminous intensity with a millicandela rating of 2390mcd
• Designed for low power consumption in indicator applications

LED Indication - Discrete Applications

• Panel status indicators
• Power supply status lights
• Electronic equipment front panels
• Control board signaling

LED Indication - Discrete Procurement Notes

Verify the specific ordering suffix to ensure compatibility with required lens color and packaging format. Confirm RoHS compliance status if environmental regulations apply to the end product. Cross-reference the datasheet electrical parameters against circuit design requirements to ensure proper current limiting resistor selection. Check manufacturer documentation for any updates regarding pin configuration or mechanical dimensions prior to finalizing procurement orders.

LED Indication - Discrete Selection Notes

Select this component when a standard 3mm through-hole red LED is required for general indication tasks. Consider the 2.2V forward voltage drop when designing the driving circuit to ensure adequate headroom. The clear lens option offers higher brightness compared to diffused variants, making it suitable for direct line-of-sight viewing. Evaluate the mechanical constraints of the enclosure to accommodate the radial lead spacing and overall height of the T-1 package.

LED Indication - Discrete Part Context

This part belongs to SunLED's discrete LED indication series, focusing on cost-effective solutions for consumer and industrial electronics. The T-1 form factor represents a legacy but widely used size for panel mounting. SunLED manufactures these components under ISO9001 and ISO14001 certified processes, ensuring consistent quality across their optoelectronic product lines.

LED Indication - Discrete Replacement Considerations

Direct substitutes must match the 3mm T-1 radial package, red color, and similar electrical characteristics. Verify that alternative parts maintain comparable forward voltage and luminous intensity to ensure identical visual performance in the application.
