Edgeboard Connectors

Card edge or edgeboard connectors are a style of connector system in which (typically) a pattern of exposed copper regions at the periphery of a printed circuit board constitutes one-half of a mating connector pair. A common use case being the connection of accessory cards such as graphics accelerators to computer motherboards in desktop PC applications, they offer a relatively low-cost, high density interconnect option for applications where durability is not a primary concern.

Screen Default Ranking Price By Date

Select products	Mfr	Description	Package	Supplier Device Package	Mounting Type	Series	Operating Temperature
306-009-520-158 $8.93	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Panel Mount, Through Hole	306	-40°C ~ 105°C
306-009-520-168 $8.93	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Panel Mount, Through Hole	306	-40°C ~ 105°C
306-009-520-178 $8.93	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Panel Mount, Through Hole	306	-40°C ~ 105°C
306-009-521-101 $6.44	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Through Hole	306	-40°C ~ 105°C
306-009-521-102 $6.44	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Panel Mount, Through Hole	306	-40°C ~ 105°C
306-009-521-103 $8.29	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Panel Mount, Through Hole	306	-40°C ~ 105°C
306-009-521-104 $6.44	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Panel Mount, Through Hole	306	-40°C ~ 105°C
306-009-521-107 $8.29	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Panel Mount, Through Hole	306	-40°C ~ 105°C
