1.5SMC350

1.5SMC350 is listed in the Tvs Diodes range at ChipApex. The manufacturer field lists Diotec Semiconductor. Its product description is TVS DIODE 284VWM 504VC DO214AB. Review the specifications below when checking this part for your BOM.

Tvs Diodes specifications for 1.5SMC350

• Description：TVS DIODE 284VWM 504VC DO214AB
• Series：-
• Mfr：Diotec Semiconductor
• Package：Tape & Reel (TR)
• Type：Zener
• Bidirectional Channels：-
• Voltage - Reverse Standoff (Typ)：284V
• Voltage - Breakdown (Min)：315V
• Voltage - Clamping (Max) @ Ipp：504V
• Current - Peak Pulse (10/1000µs)：3A
• Power - Peak Pulse：1500W (1.5kW)
• Power Line Protection：No
• Applications：General Purpose
• Capacitance @ Frequency：-
• Operating Temperature：-50°C ~ 150°C (TJ)
• Mounting Type：Surface Mount
• Package / Case：DO-214AB, SMC
• Supplier Device Package：DO-214AB (SMC)
• Unidirectional Channels：1
• Grade：-
• Qualification：-

Tvs Diodes datasheet and documents for 1.5SMC350
