1-776230-2

$17.98

Description：CONN HEADER VERT 35POS 4MM
Series：AMPSEAL
Mfr：TE Connectivity AMP Connectors
Package：Bulk

SKU:01a756da5646 Category: Headers, Male Pins Brand: TE Connectivity AMP Connectors

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

1-776230-2 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists TE Connectivity AMP Connectors. Its product description is CONN HEADER VERT 35POS 4MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 1-776230-2

Description：CONN HEADER VERT 35POS 4MM
Series：AMPSEAL
Mfr：TE Connectivity AMP Connectors
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.157" (4.00mm)
Number of Positions：35
Number of Rows：3
Row Spacing - Mating：0.157" (4.00mm)
Number of Positions Loaded：All
Style：Board to Cable/Wire
Shrouding：Shrouded - 4 Wall
Mounting Type：Panel Mount, Through Hole
Termination：Solder
Fastening Type：Locking Ramp
Contact Length - Mating：-
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：-
Contact Shape：Circular
Contact Finish - Mating：Gold-Palladium
Contact Finish Thickness - Mating：-
Contact Finish - Post：-
Contact Material：Brass
Insulation Material：Polybutylene Terephthalate (PBT), Glass Filled
Features：Mounting Flange, Sealable
Operating Temperature：-40°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：-
Insulation Color：Natural
Current Rating (Amps)：Varies by Wire Gauge
Voltage Rating：250VAC

Headers, Male Pins datasheet and documents for 1-776230-2

1-776230-2

Headers, Male Pins Overview

The 1-776230-2 is an automotive connector from the AMPSEAL series, manufactured by TE Connectivity AMP Connectors. It is a straight header with three rows and thirty-five contacts designed for PCB pin termination. The component features a voltage rating of 250 VAC and utilizes a straight mounting angle configuration.

Headers, Male Pins Feature Summary

Three-row header configuration for high-density interconnect applications
Designed for direct PCB pin termination in automotive environments
Rated for 250 VAC electrical operation

Headers, Male Pins Applications

Automotive electronic control units
Vehicle wiring harness systems
On-board diagnostic interfaces

Headers, Male Pins Procurement Notes

Verify current manufacturing status and availability through authorized TE Connectivity channels. Confirm that the specified part number matches the required three-row, thirty-five contact configuration. Ensure compatibility with existing PCB layouts and mating connectors before procurement.

Headers, Male Pins Selection Notes

Select this component when a three-row, thirty-five contact automotive header is required. Verify that the 250 VAC rating meets system requirements. Confirm that the straight PCB pin termination style aligns with the target printed circuit board design and assembly process.

Headers, Male Pins Part Context

This component belongs to the AMPSEAL series, a line of automotive connectors produced by TE Connectivity AMP Connectors. The AMP brand has a long history in connector technology, originally established in 1941 and now operating under TE Connectivity. The AMPSEAL series is specifically engineered for demanding automotive applications requiring reliable electrical connections.
