1-794618-0

Headers, Male Pins Overview

The 1-794618-0 is a Micro MATE-N-LOK series header assembly manufactured by TE Connectivity. It features a right-angle, through-hole mounting configuration with 20 positions arranged in a 2-row layout. The connector utilizes a 3.00 mm (0.118 inch) pitch and employs shrouded four-wall design for polarity assurance. Contacts are tin-plated over nickel brass, rated for 250 V and supporting wire-to-board connections.

Headers, Male Pins Feature Summary

• Right-angle board-to-wire architecture facilitates compact PCB integration
• Shrouded four-wall housing ensures correct mating alignment and polarity
• Through-hole termination provides robust mechanical stability on printed circuit boards

Headers, Male Pins Applications

• Industrial control system interconnects
• Consumer electronics internal wiring
• Computer peripheral assemblies

Headers, Male Pins Procurement Notes

Verify the specific contact plating finish and housing color against project requirements, as variations exist within the Micro MATE-N-LOK family. Confirm that the right-angle orientation matches the PCB footprint constraints. Ensure compatible crimping tools and mating sockets are sourced from the same manufacturer to guarantee proper engagement and electrical performance.

Headers, Male Pins Selection Notes

Select this component when a rigid, right-angle connection is required between a PCB and wire harness. The 20-position capacity suits moderate density applications. Verify that the tin-plated contacts meet corrosion resistance needs for the operating environment. Consider thermal management if high current loads are present, as the standard rating applies to specific conditions.

Headers, Male Pins Part Context

This part belongs to the Micro MATE-N-LOK line, designed for general-purpose signal and low-power applications. It complements matching socket housings and individual pin contacts. The series is widely used in automotive and industrial sectors where reliable, cost-effective interconnects are necessary. It represents a standard solution for fixed board-to-wire interfaces.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other 20-position, 3.00mm pitch right-angle headers from the same Micro MATE-N-LOK series, such as 5-794618-0 or 4-794618-0, provided the contact plating and terminal type match the original design specifications.
