1-794631-6

Headers, Male Pins Overview

The TE Connectivity AMP Connectors part number 1-794631-6 is a vertical header connector belonging to the Micro MATE-N-LOK series. It features an 8-position configuration with a 0.118-inch (3.00mm) mating pitch and a 2-row arrangement. The connector utilizes male pin contacts made of brass, housed in black polyamide insulation rated UL94 V-0. Designed for through-hole mounting, it supports board-to-cable or wire applications with a shrouded four-wall design. The unit operates within a temperature range of -40°C to 105°C and carries a voltage rating of 250V.

Headers, Male Pins Feature Summary

• Micro MATE-N-LOK series construction provides reliable grouping for multiple lead connections
• Shrouded four-wall housing ensures proper alignment and secure mating
• Vertical orientation facilitates direct printed circuit board integration
• Through-hole termination method offers robust mechanical stability

Headers, Male Pins Applications

• Board-to-cable interconnections
• Wire-to-board assemblies
• General electronic equipment signal routing

Headers, Male Pins Procurement Notes

Verify the specific suffix and revision level against the official datasheet to ensure compatibility with existing tooling and mating components. Confirm that the required contact plating matches the application environment requirements. Check for obsolescence notices or lifecycle status updates from the manufacturer before finalizing procurement plans.

Headers, Male Pins Selection Notes

Select this component when a vertical, shrouded header with a 3.00mm pitch is required for high-reliability connections. Ensure the PCB layout accommodates the through-hole footprint and the housing height. Verify that the mating cable assembly utilizes compatible Micro MATE-N-LOK terminals and housings to maintain electrical continuity and mechanical integrity.

Headers, Male Pins Part Context

This connector is part of the widely adopted Micro MATE-N-LOK family, known for cost-effective and reliable multi-lead grouping. The series is engineered for general-purpose applications requiring durable board-to-wire interfaces. TE Connectivity AMP Connectors manufactures this line to support diverse industrial and commercial electronics needs.

Headers, Male Pins Replacement Considerations

Direct substitute part numbers are not confirmed in the provided documentation. Verify cross-reference availability through official TE Connectivity channels if replacement is necessary due to supply constraints.
