1-794677-0

Headers, Male Pins Overview

The TE Connectivity AMP Connectors part number 1-794677-0 is a rectangular connector header assembly belonging to the MATE-N-LOK series. It features a right-angle configuration with 10 positions and a 3.00mm pitch. The component utilizes male pin contacts with tin plating, designed for through-hole termination on printed circuit boards. The housing is constructed from black nylon material rated UL 94 V-0 for flammability. This connector supports a voltage rating of 250V and a current rating of 5A per contact.

Headers, Male Pins Feature Summary

• Right-angle header design facilitates compact PCB layout integration
• Tin-plated male pin contacts ensure reliable electrical conductivity
• Nylon housing provides structural integrity and UL 94 V-0 flame resistance

Headers, Male Pins Applications

• General purpose electronic interconnections
• Industrial control system wiring
• Consumer electronics assemblies

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the manufacturer's official documentation to confirm exact pin count, orientation, and termination style. Ensure compatibility with mating socket connectors within the same MATE-N-LOK family. Confirm that the tin plating specification meets the environmental requirements of the intended application before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a right-angle, 10-position header is required for general-purpose applications. Consider the 3.00mm pitch and 5A current rating to ensure adequate performance margins. Verify that the through-hole mounting style aligns with the target PCB manufacturing capabilities and mechanical constraints of the enclosure design.

Headers, Male Pins Part Context

This component is part of the extensive MATE-N-LOK product line manufactured by TE Connectivity AMP Connectors. The MATE-N-LOK series is widely recognized for its robust locking mechanism and versatile range of configurations. As a standard rectangular connector, it serves as a fundamental interconnection solution across various industrial and commercial electronic systems requiring secure signal or power transmission.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other 10-position right-angle headers from the MATE-N-LOK series, such as part numbers 5-794677-0 or 3-794677-6, provided they match the 3.00mm pitch and through-hole termination requirements. Always verify cross-references using official TE Connectivity documentation.
