1-87232-0

Headers, Male Pins Overview

The 1-87232-0 is a PCB header connector from the AMPMODU Mod II series, manufactured by TE Connectivity AMP Connectors. It features a right-angle through-hole mounting style with 12 positions in a single row. The connector utilizes a 0.100-inch (2.54 mm) mating pitch and accepts all pins. Contact materials are phosphor bronze with gold plating on both mating and post surfaces. The insulation is black polyamide reinforced with glass fiber, rated UL94 V-0. Rated current is 3A, operating temperature range is -65°C to 105°C.

Headers, Male Pins Feature Summary

• Right-angle through-hole design for board-to-board or cable connections
• Gold-plated phosphor bronze contacts for reliable signal transmission
• UL94 V-0 rated glass-reinforced polyamide insulation
• Push-pull locking mechanism for secure engagement

Headers, Male Pins Applications

• Industrial control systems requiring robust interconnects
• Consumer electronics internal circuit boards
• Automotive electronic modules
• General-purpose printed circuit board assemblies

Headers, Male Pins Procurement Notes

Verify component authenticity through authorized TE Connectivity distributors. Confirm lot codes and RoHS compliance status against current manufacturing records. Check for obsolescence notices as this part may have limited availability. Ensure storage conditions maintain humidity sensitivity levels per JEDEC standards before reflow soldering.

Headers, Male Pins Selection Notes

Select this header when right-angle mounting is required for space-constrained designs. The 2.54mm pitch suits standard PCB layouts. Verify mating receptacle compatibility within the AMPMODU Mod II family. Consider thermal management requirements given the 3A rating and plastic housing material properties during high-current applications.

Headers, Male Pins Part Context

Part of the established AMPMODU Mod II line, known for reliability in industrial environments. This specific variant offers a compact 12-position configuration suitable for dense circuit layouts. The series provides standardized dimensions ensuring interchangeability across various TE Connectivity connector families.

Headers, Male Pins Replacement Considerations

Consult TE Connectivity official documentation for direct cross-reference parts. Verify mechanical fit and electrical specifications match before substitution. No confirmed substitute part numbers are publicly documented for this specific obsolete variant.
