103670-8

Headers, Male Pins Overview

The 103670-8 is a vertical header connector from the AMPMODU MOD IV series, manufactured by TE Connectivity AMP Connectors. It features a 2-position configuration with a 0.100 inch (2.54mm) pitch. Designed for cable installation, this component utilizes a female contact type and is constructed with nylon insulation in a straight orientation. The connector supports through-hole termination methods and operates within a temperature range of -65°C to 105°C. It meets UL94 V-0 material flammability ratings and carries a current rating of 3A at 267V.

Headers, Male Pins Feature Summary

• Vertical header design for direct PCB mounting
• AMPMODU MOD IV series compatibility
• Nylon insulation with UL94 V-0 rating
• Through-hole termination capability

Headers, Male Pins Applications

• Electronic assemblies
• Wiring harnesses
• PCB applications

Headers, Male Pins Procurement Notes

Verify the specific manufacturer part number against official TE Connectivity documentation to ensure authenticity. Confirm that the received components match the AMPMODU MOD IV series specifications. Check for physical integrity of the nylon housing and verify that the contacts are undamaged. Ensure compliance with required environmental operating temperatures before integration into final systems.

Headers, Male Pins Selection Notes

Select this component when a low-profile vertical interconnect is required for signal transmission. The 2.54mm pitch ensures compatibility with standard board layouts. Consider the 3A current rating for power distribution needs. Verify that the cable installation style aligns with the mechanical constraints of the enclosure design.

Headers, Male Pins Part Context

This connector belongs to the AMPMODU MOD IV family, a widely used line of rectangular connectors known for reliability. The series offers various configurations for board-to-board and cable connections. TE Connectivity AMP Connectors provides extensive support for this product line across industrial and commercial sectors.

Headers, Male Pins Replacement Considerations

Consult official cross-reference guides for compatible alternatives. Ensure substitute parts maintain identical pitch, pin count, and mounting style. Verify that any replacement meets the same electrical and thermal performance standards.
