1054301105

Headers, Male Pins Overview

The Molex 105430-1105 is a Nano-Fit right-angle header designed for surface mount applications. It features a single row with five contacts and a 2.50mm pitch. The connector utilizes male pins with 0.76µm tin plating and is housed in black material capable of glow-wire testing.

Headers, Male Pins Feature Summary

• Surface mount right-angle configuration
• Glow-wire capable housing material
• Single row, five-contact design

Headers, Male Pins Applications

• High performance peripheral devices
• Harsh condition environments
• Wire-to-board connections

Headers, Male Pins Procurement Notes

Verify the part number includes the dash (105430-1105) to ensure accuracy against the Nano-Fit series specifications. Confirm that the required surface mount footprint matches the datasheet dimensions. Ensure the procurement source provides official documentation confirming the glow-wire capability and tin plating thickness.

Headers, Male Pins Selection Notes

Select this component when a compact, high-density connection is required for wire-to-board interfaces. The right-angle orientation facilitates space-constrained PCB layouts. Verify that the operating environment supports the specified glow-wire rating and that the 2.50mm pitch aligns with the system's routing requirements.

Headers, Male Pins Part Context

This part belongs to the Nano-Fit family, characterized by its compact 1mm-pitch design variants adapted for specific current ratings. The 105430 series specifically addresses surface mount needs, offering durability in demanding conditions compared to standard through-hole alternatives.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided data. Cross-referencing requires matching the 2.50mm pitch, right-angle form factor, and surface mount termination style.
