2147210040

Headers, Receptacles, Female Sockets Overview

The Molex 2147210040 is a Zero-Hachi header connector featuring a 0.80mm pitch and four positions in a single row. Designed for surface mount, right-angle installation, it utilizes friction lock retention. The contacts are made of copper alloy with matte tin plating on both mating and termination interfaces. It operates within a temperature range of -40°C to +105°C and carries an UL94 V-0 flammability rating.

Headers, Receptacles, Female Sockets Feature Summary

• Zero-Hachi series design optimized for high-density applications
• Friction lock mechanism ensures secure connection stability
• Right-angle surface mount configuration facilitates compact PCB layouts

Headers, Receptacles, Female Sockets Applications

• High-performance peripheral device interconnects
• Harsh condition environments requiring durability
• Compact consumer electronics assemblies

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific part number against official Molex documentation to confirm the matte tin plating variant. Ensure compatibility with surface mount processes and check for any updated environmental compliance certifications prior to procurement.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a 0.80mm pitch header with right-angle orientation is required. The friction lock feature provides mechanical stability without additional latching hardware. Verify that the matte tin plating meets the corrosion resistance requirements for the intended operating environment.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Zero-Hachi family, known for compact wire-to-board solutions. It serves as a right-angle alternative to standard headers, enabling efficient space utilization on printed circuit boards while maintaining reliable electrical connections in dense configurations.

Headers, Receptacles, Female Sockets Replacement Considerations

The 2147210041 is a direct substitute within the same series, differing only by gold plating instead of matte tin. Both share identical mechanical dimensions and pin counts.
