2147210080

Headers, Receptacles, Female Sockets Overview

The Molex 2147210080 is an eight-position header connector from the Zero-Hachi series, designed for surface-mount right-angle PCB installation. It features a 0.80mm pitch and utilizes friction lock retention mechanisms. The contacts are tin-plated copper alloy with a 39.4µin (1.00µm) thickness. Rated for 30V and 1A, it operates within a -40°C to 85°C range. The LCP insulation is black and UL94 V-0 rated. This component supports general-purpose and telecommunications applications.

Headers, Receptacles, Female Sockets Feature Summary

• Zero-Hachi fine-pitch system offering low-profile height
• Friction lock retention mechanism for secure mating
• Surface-mount right-angle design for space-constrained boards

Headers, Receptacles, Female Sockets Applications

• General-purpose electronics interconnects
• Telecommunications equipment signal routing

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific packaging configuration required for production, as this part number is available in tape and reel, cut tape, or Digi-Reel formats. Confirm that the zero-hachi mating receptacles match the 0.80mm pitch specification. Ensure the surface-mount footprint aligns with the manufacturer's provided CAD models to guarantee proper solder joint integrity during assembly processes.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when board space is limited due to its low-profile construction and fine 0.80mm pitch. The right-angle orientation facilitates vertical cabling connections. Verify that the 1A current rating and 30V voltage limit meet the circuit requirements. The friction lock feature eliminates the need for additional screw fasteners, simplifying the assembly workflow compared to threaded alternatives.

Headers, Receptacles, Female Sockets Part Context

This header belongs to the Zero-Hachi connector system, which focuses on high-density interconnect solutions for portable digital products and compact consumer electronics. The series is characterized by its miniature form factor and reliability in demanding environments. Molex developed this line to address the industry trend toward miniaturization while maintaining robust electrical performance standards.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct substitutes must maintain the 0.80mm pitch, 8-position count, and right-angle surface-mount configuration. Verify compatibility with existing mating receptacles before swapping manufacturers. Generic equivalents may differ in insulation material properties or retention force specifications.
