Headers, Receptacles, Female Sockets Overview

Molex part number 22142124 is a 12-position socket connector housing from the KK Interconnection System. It features a 0.100-inch (2.54mm) pitch and is designed for through-hole mounting with bottom entry orientation. The component utilizes a tin-plated finish on its contacts to ensure reliable electrical performance. This housing is engineered for wire-to-board applications, providing a secure mechanical interface for mating with corresponding pin terminals.

Headers, Receptacles, Female Sockets Feature Summary

• Supports 12-position configurations within the KK Interconnection System
• Designed for bottom entry orientation in through-hole assemblies
• Utilizes tin-plated contact finishes for corrosion resistance

Headers, Receptacles, Female Sockets Applications

• Wire-to-board interconnections
• Through-hole PCB assembly
• Electronic device internal wiring

Headers, Receptacles, Female Sockets Procurement Notes

Verify that the specific order matches Molex part number 22142124 or its equivalent prefixes such as 0022142124. Confirm the 12-position count and bottom entry orientation are required for the design. Ensure compatibility with standard 0.100 inch pitch terminals. Check RoHS compliance status against current regulatory requirements before finalizing procurement.

Headers, Receptacles, Female Sockets Selection Notes

Select this housing when a 12-contact board-mount solution is needed. The 2.54mm pitch suits general-purpose electronics. Bottom entry facilitates specific routing layouts. Tin plating offers standard durability. Verify that the KK system meets the voltage and current ratings of the application environment.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the KK Interconnection System, a widely used series for general-purpose connectivity. It complements other housings and terminals within the same pitch family. The 22142124 variant specifically addresses multi-channel board connections. It integrates with Molex's broader portfolio of power and signal solutions.

Headers, Receptacles, Female Sockets Replacement Considerations

Equivalent part numbers include 0022142124 and 22-14-2124. These identifiers refer to the same 12-position bottom entry housing. Cross-reference these codes to ensure supply chain flexibility without altering technical specifications.
