243-004-542-201

$9.69

Description：CONN EDGE DUAL FMALE 4POS 0.200
Series：243
Mfr：EDAC Inc.
Package：Bulk

SKU:ecae53b4c2da Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

243-004-542-201 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE DUAL FMALE 4POS 0.200. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 243-004-542-201

Description：CONN EDGE DUAL FMALE 4POS 0.200
Series：243
Mfr：EDAC Inc.
Package：Bulk
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：2
Number of Positions：4
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：2
Pitch：0.200" (5.08mm)
Read Out：Dual
Features：-
Mounting Type：Through Hole
Termination：Solder Eyelet(s)
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：-
Contact Type：Cantilever
Color：White
Flange Feature：-
Operating Temperature：-40°C ~ 105°C

Edgeboard Connectors datasheet and documents for 243-004-542-201

243-004-542-201

Edgeboard Connectors Overview

The EDAC Inc. 243-004-542-201 is a standard card edge connector from the 243 Series, designed for dual-edge board insertion. It features 4 positions with a 5.08 mm (0.200 inch) pitch. The connector utilizes gold-plated contacts and accepts boards with a thickness of 0.200 inches. Constructed with a white insulator, it supports through-hole termination for reliable signal transmission in electronic assemblies.

Edgeboard Connectors Feature Summary

Dual-edge card interface design
Gold contact finish for conductivity
Through-hole mounting style

Edgeboard Connectors Applications

Electronic circuit board interconnection
Industrial control modules
Communication equipment backplanes

Edgeboard Connectors Procurement Notes

Verify the specific datasheet version to confirm current RoHS compliance status and detailed mechanical dimensions. Ensure compatibility with the target PCB trace width and hole size before integration. Cross-reference the manufacturer's latest documentation to validate material specifications and environmental ratings for your specific application requirements.

Edgeboard Connectors Selection Notes

Select this component when a low-count, high-pitch dual-edge connector is required. The 5.08 mm spacing accommodates larger traces compared to fine-pitch alternatives. Verify that the target PCB thickness matches the 0.200-inch specification to ensure proper retention and electrical contact stability during operation.

Edgeboard Connectors Part Context

This part belongs to the EDAC 243 Series, which offers various position counts and pitch options. It is categorized under standard card edge connectors, distinct from high-temperature or specialized medical series. The numbering convention indicates position count and pitch characteristics within the broader EDAC product family.
