302-006-656-201

Edgeboard Connectors Overview

The EDAC Inc. 302-006-656-201 is a standard card edge connector from the 302 series, designed for dual-edge board applications. It features six female positions with a contact spacing of 0.050 inches (1.27mm). The contacts are gold-plated to ensure reliable signal transmission and corrosion resistance. This component utilizes a non-specified dual-edge card type configuration, making it suitable for various electronic interconnection needs requiring precise alignment and secure mating.

Edgeboard Connectors Feature Summary

• Dual-row formation with extender board tails for enhanced mechanical stability
• Gold flash plated contacts for superior conductivity and durability
• Housing design without mounting lugs for flexible integration

Edgeboard Connectors Applications

• Medical interconnect solutions
• Standard card edge circuit boards
• Electronic device signal routing

Edgeboard Connectors Procurement Notes

Verify availability status as supply may be restricted in certain regions. Confirm that the ordering suffix does not alter functional specifications unless explicitly stated by the manufacturer. Ensure compatibility with target PCB thickness and mating card dimensions before finalizing procurement decisions.

Edgeboard Connectors Selection Notes

Select this model when a low-profile, dual-edge connector with fine pitch is required. Consider the absence of mounting lugs for space-constrained designs. Verify that the gold flash plating meets environmental requirements for the intended application environment.

Edgeboard Connectors Part Context

This part belongs to the EDAC 302 series, which specializes in card edge connectors with 0.05-inch contact spacing. The series offers various position counts and termination options, catering to diverse electronic assembly needs while maintaining consistent dimensional standards across the family.

Edgeboard Connectors Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Consult official EDAC catalogs for potential cross-references if alternative sourcing is necessary.
