305-014-520-503

Edgeboard Connectors Overview

The EDAC Inc. 305-014-520-503 is a dual-row card edge connector from the 305 Series, designed for panel mount and through-hole installation. It features 14 positions with a 0.156-inch (3.96mm) pitch. The connector utilizes copper alloy contacts with gold plating and a half-beehive contact type. It is rated for a card thickness of 0.054 to 0.070 inches (1.37mm to 1.78mm). The unit operates within a temperature range of -40°C to 105°C and uses thermoplastic polyester insulation.

Edgeboard Connectors Feature Summary

• Dual-row configuration with 14 total positions for high-density signal routing
• Gold-plated copper alloy half-beehive contacts ensure reliable electrical connection
• Thermoplastic polyester insulation provides structural stability and thermal resistance
• Panel mount and through-hole termination supports secure mechanical integration

Edgeboard Connectors Applications

• Industrial control system interconnects
• Telecommunications equipment backplanes
• Automotive electronic module connections
• Test and measurement instrument interfaces

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against the official EDAC 305 Series Ordering Guide to confirm exact physical dimensions and flange characteristics. Ensure compatibility with the target PCB layout regarding hole spacing and mounting orientation. Confirm that the specified card thickness falls within the 0.054 to 0.070 inch operational range for proper contact engagement.

Edgeboard Connectors Selection Notes

Select this component when a dual-row, 14-position interface is required with a standard 3.96mm pitch. It is suitable for applications demanding robust panel mounting with through-hole soldering. Consider the operating temperature range and material composition if environmental resilience is critical. Validate that the mating card meets the specified thickness constraints for optimal performance.

Edgeboard Connectors Part Context

This part belongs to the EDAC 305 Series, which offers various configurations for card edge applications. The series includes options for different row counts, pitches, and mounting styles. The 305-014-520-503 specifically addresses needs for moderate pin counts with dual-sided access, fitting into broader industrial and commercial electronics assembly workflows requiring standardized edge connectors.

Edgeboard Connectors Replacement Considerations

Consult the EDAC 305 Series cross-reference documentation for direct substitutes. Verify that any alternative maintains identical pitch, position count, and mounting style to ensure board compatibility.
