305-016-500-258

Edgeboard Connectors Overview

The EDAC Inc. 305-016-500-258 is a standard card edge connector from the 305 series, designed for panel mount applications. It features 16 positions arranged in a dual row configuration with a 3.96 mm (0.156 inch) pitch. The connector utilizes female contacts with gold plating and terminates via solder eyelets. It is rated for 5 A current and operates within a temperature range of -40°C to +105°C. The housing is constructed from thermoplastic material, providing an insulation resistance of 5 GOhms.

Edgeboard Connectors Feature Summary

• Dual-row female contact design for non-specified dual-edge cards
• Gold-plated copper alloy contacts ensure reliable signal transmission
• Thermoplastic housing provides structural integrity and electrical insulation
• Solder eyelet termination supports secure panel mounting

Edgeboard Connectors Applications

• Industrial control system interconnects
• Telecommunications equipment backplanes
• Test and measurement instrument interfaces
• Embedded computing module connections

Edgeboard Connectors Procurement Notes

Verify component authenticity through authorized EDAC distributors or certified suppliers. Confirm RoHS compliance status and specific lot traceability requirements prior to purchase. Ensure storage conditions maintain moisture sensitivity levels as defined by manufacturer guidelines. Cross-reference ordering suffixes to confirm exact pin count and termination style matches project specifications.

Edgeboard Connectors Selection Notes

Select this model when dual-edge card insertion requires robust panel-mounted connectivity. The 3.96 mm pitch accommodates standard board thicknesses while maintaining high-density positioning. Gold plating offers superior corrosion resistance compared to tin alternatives. Verify that the 5 A current rating aligns with system power distribution requirements and thermal management capabilities.

Edgeboard Connectors Part Context

This component belongs to the EDAC 305 series of standard card edge connectors. The series provides various position counts and termination options for diverse industrial applications. The 305-016 variant specifically addresses needs for moderate density dual-row connections. It complements other series like 315 and 355 which offer alternative mounting or guide solutions.

Edgeboard Connectors Replacement Considerations

Direct substitutes include EDAC part numbers with identical 16-position dual-row configurations and matching 3.96 mm pitch. Verify compatibility regarding solder eyelet termination style and panel mount orientation. Alternative series may require mechanical adaptation due to differing flange dimensions or guide hole placements.
