305-016-556-512

Edgeboard Connectors Overview

The EDAC Inc. 305-016-556-512 is a standard card edge connector header featuring 16 positions arranged in a dual-row configuration. It utilizes a 3.96 mm (0.156 inch) contact pitch and accepts printed circuit boards with a nominal thickness of 1.57 mm (0.062 inch). The contacts are constructed from copper alloy with gold plating to ensure reliable signal transmission. Designed for panel mounting at a vertical angle, this component provides secure interconnection for edgeboard applications within the specified electrical parameters.

Edgeboard Connectors Feature Summary

• Dual-edge female contact design accommodates non-specified board types
• Gold-plated copper alloy contacts ensure corrosion resistance
• Vertical panel mount style facilitates structural integration

Edgeboard Connectors Applications

• Industrial control system interconnects
• Telecommunications equipment backplanes
• Test and measurement instrument modules

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against the manufacturer's official datasheet to confirm compatibility with required board thicknesses and mounting configurations. Ensure that the selected variant matches the necessary current ratings and environmental specifications for the intended operational context before finalizing procurement orders.

Edgeboard Connectors Selection Notes

Select this component when a dual-row card edge interface with a 3.96 mm pitch is required for vertical panel mounting. Consider the 1.57 mm board thickness tolerance and verify that the gold-plated contact material meets the necessary conductivity and durability requirements for the target application environment.

Edgeboard Connectors Part Context

This connector belongs to the EDAC 305 series, which offers various position counts and row configurations. The series is designed for robust industrial connectivity, providing standardized dimensions and reliable performance for high-density electronic assemblies requiring secure card-to-board or card-to-panel interfaces.

Edgeboard Connectors Replacement Considerations

Compatible substitutes include EDAC part numbers 305-016-556-504 and 305-016-556-512 variants with matching 16-position and 3.96 mm pitch specifications. Verify mechanical fit and electrical ratings before substitution.
