345-020-524-808

$7.09

Description：CONN EDGE DUAL FMALE 20POS 0.100
Series：345
Mfr：EDAC Inc.
Package：Box

SKU:34574e36f0c6 Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

345-020-524-808 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE DUAL FMALE 20POS 0.100. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 345-020-524-808

Description：CONN EDGE DUAL FMALE 20POS 0.100
Series：345
Mfr：EDAC Inc.
Package：Box
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：10
Number of Positions：20
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：2
Pitch：0.100" (2.54mm)
Read Out：Dual
Features：-
Mounting Type：Through Hole
Termination：Solder
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：10.0µin (0.25µm)
Contact Type：Cantilever
Color：Green
Flange Feature：Top Mount Opening, Threaded Insert, 4-40
Operating Temperature：-40°C ~ 105°C

Edgeboard Connectors datasheet and documents for 345-020-524-808

345-020-524-808

Edgeboard Connectors Overview

The EDAC Inc. 345-020-524-808 is a standard card edge connector featuring 20 positions with a 0.100 inch (2.54 mm) pitch. Designed for dual-edge mating, this female connector utilizes gold-plated copper alloy contacts and PC pin termination. It supports through-hole vertical mounting and accommodates board thicknesses ranging from 0.054 to 0.070 inches. The unit operates within a temperature range of -40°C to 105°C.

Edgeboard Connectors Feature Summary

Dual-edge female contact configuration for secure board insertion
Gold-plated copper alloy contacts ensuring reliable conductivity
Vertical through-hole mounting with PC pin termination

Edgeboard Connectors Applications

Industrial control system backplanes
Telecommunications equipment interconnects
Consumer electronics module connections

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against official EDAC documentation to confirm exact physical dimensions and plating specifications. Ensure compatibility with target PCB stack-up and mating card thickness requirements before finalizing procurement orders.

Edgeboard Connectors Selection Notes

Select this component when dual-edge connectivity is required for 20-position applications. Confirm that the 0.100-inch pitch aligns with the design layout and that the vertical orientation fits the enclosure constraints.

Edgeboard Connectors Part Context

This part belongs to the EDAC 345 series of standard card edge connectors. The series offers various position counts and mounting styles, providing modular solutions for diverse electronic assembly needs across multiple industries.

Edgeboard Connectors Replacement Considerations

Consult official EDAC substitution guides for direct replacements. Verify mechanical footprint and electrical ratings match before considering alternative manufacturers.
