395-011-558-412

$9.53

Description：CONN EDGE SINGLE FML 11POS 0.100
Series：395
Mfr：EDAC Inc.
Package：Box

SKU:b604171c03ae Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

395-011-558-412 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE SINGLE FML 11POS 0.100. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 395-011-558-412

Description：CONN EDGE SINGLE FML 11POS 0.100
Series：395
Mfr：EDAC Inc.
Package：Box
Card Type：Non Specified - Single Edge
Gender：Female
Number of Positions/Bay/Row：11
Number of Positions：11
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：1
Pitch：0.100" (2.54mm)
Read Out：Single
Features：-
Mounting Type：Through Hole, Right Angle
Termination：Solder
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：10.0µin (0.25µm)
Contact Type：Cantilever
Color：Black
Flange Feature：Side Mount Opening, Unthreaded, 0.128" (3.25mm) Dia
Operating Temperature：-40°C ~ 105°C

Edgeboard Connectors datasheet and documents for 395-011-558-412

395-011-558-412

Edgeboard Connectors Overview

The EDAC Inc. 395-011-558-412 is a single-row card edge connector designed for vertical panel mount applications. It features 11 positions with a 0.100-inch (2.54mm) pitch and utilizes female contacts. The component employs solder pin termination and includes guide sets for alignment. Constructed with copper alloy contacts featuring gold plating, the insulator is black thermoplastic polyester. It supports PCB thicknesses of 1.57mm and operates within a temperature range of -40°C to 105°C.

Edgeboard Connectors Feature Summary

Vertical panel mount configuration with integrated guide sets
Single row of 11 female contacts with gold plating
Solder pin termination for secure board attachment

Edgeboard Connectors Applications

Industrial control systems requiring vertical interconnects
Communication equipment backplanes
Automotive electronics modules

Edgeboard Connectors Procurement Notes

Verify the specific suffix codes against manufacturer documentation to confirm exact termination style and mounting variations. Ensure compatibility with target PCB thickness specifications before integration. Cross-reference RoHS compliance status with current regulatory requirements for the intended market.

Edgeboard Connectors Selection Notes

Select this model when vertical orientation and guide set alignment are required for single-row connections. Confirm that the 0.100-inch pitch matches the design footprint. Verify that the solder pin termination method aligns with the assembly process capabilities.

Edgeboard Connectors Part Context

This component belongs to the EDAC 395 series of standard card edge connectors. The series offers various position counts and termination styles. This specific part number represents a 11-position variant optimized for vertical mounting scenarios in compact electronic assemblies.
