4-1608065-9

4-1608065-9 is listed in the Power Relays, Over 2 Amps range at ChipApex. The manufacturer field lists TE Connectivity Potter & Brumfield Relays. Its product description is RELAY GEN PURPOSE DPDT 20A 24V. Review the specifications below when checking this part for your BOM.

Power Relays, Over 2 Amps specifications for 4-1608065-9

• Description：RELAY GEN PURPOSE DPDT 20A 24V
• Series：187
• Mfr：TE Connectivity Potter & Brumfield Relays
• Package：Bulk
• Mounting Type：Chassis Mount
• Coil Voltage：24VDC
• Contact Form：DPDT (2 Form C)
• Contact Rating (Current)：20 A
• Switching Voltage：240VAC, 28VDC - Max
• Load - Max Switching：4800VA, 560W
• Coil Current：50 mA
• Coil Type：Non Latching
• Features：-
• Termination Style：Quick Connect - 0.250" (6.3mm)
• Seal Rating：-
• Coil Insulation：Class B
• Must Operate Voltage：18 VDC
• Must Release Voltage：-
• Operating Temperature：-45°C ~ 70°C
• Contact Material：Silver Cadmium Oxide (AgCdO)
• Approval Agency：CSA, UR
• Relay Type：General Purpose
• Grade：-
• Qualification：-
• Operate Time：20 ms
• Release Time：10 ms

Power Relays, Over 2 Amps datasheet and documents for 4-1608065-9
