429-10-272-00-560000

Headers, Male Pins Overview

The Mill-Max 429-10-272-00-560000 is a standard pin header from the 0429 series, designed for surface mount applications. It features a double row configuration with 72 contacts and a .100 inch (2.54 mm) pitch. The connector utilizes solder cup termination for secure PCB attachment. Mating contact length is specified at 0.121 inches (3.07 mm). The unit employs a push-pull fastening mechanism and operates within bulk packaging.

Headers, Male Pins Feature Summary

• Double row surface mount pin header design
• Solder cup termination method
• Push-pull fastening type

Headers, Male Pins Applications

• Surface mount interconnects
• Standard pin header assemblies
• Headers & Wire Housings integration

Headers, Male Pins Procurement Notes

Verify component authenticity through authorized Mill-Max channels or certified distributors. Confirm RoHS compliance status via official documentation before integration. Ensure storage conditions align with manufacturer guidelines to maintain solderability and mechanical integrity of the precision-machined contacts during handling and assembly processes.

Headers, Male Pins Selection Notes

Select this part for high-density surface mount requirements needing double row connectivity. The .100 inch pitch suits standard board layouts. Verify that the 72-contact count matches circuit interface needs. Consider the push-pull fastening feature for secure mating stability in vibration-prone environments requiring reliable electrical continuity.

Headers, Male Pins Part Context

This component belongs to the Mill-Max 0429 series of headers and wire housings. Mill-Max Manufacturing Corp. specializes in precision-machined interconnect components. The company produces high-reliability connectors for industrial and electronic applications, emphasizing custom engineering capabilities and robust manufacturing standards for critical connection points.

Headers, Male Pins Replacement Considerations

Consult official Mill-Max catalogs for direct substitutes within the 0429 series. Verify identical pitch, row count, and termination style when evaluating alternatives. Cross-reference datasheet dimensions to ensure mechanical compatibility with existing board footprints and mating connector specifications.
