450-10-208-00-006000

Headers, Male Pins Overview

The Mill-Max Manufacturing Corp. part number 450-10-208-00-006000 is a vertical header connector designed for board-to-board applications. It features 8 positions arranged in a single row with a 0.100-inch (2.54mm) pitch. The connector utilizes through-hole termination and push-pull mounting methods. Contact materials consist of copper alloy with tin plating, while the insulator is made of black PCT material.

Headers, Male Pins Feature Summary

• Vertical pin header configuration for direct board stacking
• Through-hole solder termination for secure PCB attachment
• Push-pull locking mechanism for mating stability
• Tin-plated copper alloy contacts for conductivity

Headers, Male Pins Applications

• Board-to-board interconnection systems
• High-reliability precision-machined interconnect assemblies
• Industrial control cabinet installations

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to ensure correct contact length and insulation height specifications match the design requirements. Confirm RoHS3 compliance status and moisture sensitivity level classification before integration into production workflows. Cross-reference the manufacturer catalog to validate current availability and standard delivery timelines.

Headers, Male Pins Selection Notes

Select this component when a low-profile vertical header with a 2.54mm pitch is required for single-row connections. Ensure the application supports through-hole assembly processes and accommodates the specified overall contact length. Evaluate mechanical clearance constraints against the insulator height and total connector profile dimensions.

Headers, Male Pins Part Context

This component belongs to the Mill-Max 450 series, which specializes in high-reliability precision-machined interconnect components. The series is recognized for providing robust solutions in demanding industrial environments. Mill-Max Manufacturing Corp. maintains its production facilities in the United States to ensure consistent quality standards.

Headers, Male Pins Replacement Considerations

The part number 450-80-248-00-006101 from Preci-Dip is listed as an alternative option. Verify dimensional compatibility and electrical specifications before substitution.
