450-10-264-00-001000

Headers, Male Pins Overview

The Mill-Max 450-10-264-00-001000 is a vertical pin header strip featuring 64 positions with a 2.54 mm (0.100 inch) grid spacing. It utilizes a double-row configuration and solder tail termination for through-hole mounting. The component belongs to the 450 series of headers and wire housings, designed for high-reliability interconnect applications requiring precision-machined contacts.

Headers, Male Pins Feature Summary

• Vertical orientation design for standard board-to-board or wire harness connections
• Double-row arrangement providing high-density contact distribution
• Solder tail termination method ensuring secure through-hole PCB attachment

Headers, Male Pins Applications

• High-density electronic assembly interconnects
• Precision-machined circuit board signal routing
• Industrial control system hardware interfaces

Headers, Male Pins Procurement Notes

Verify current manufacturing status and lead times directly with Mill-Max Manufacturing Corp., as this item may be subject to factory special order requirements. Confirm RoHS compliance details and specific packaging quantities prior to purchase, as availability and supply chain conditions can vary significantly for precision interconnect components.

Headers, Male Pins Selection Notes

Select this part when a 64-position vertical header with 2.54 mm pitch is required. Ensure the application supports double-row through-hole soldering. Verify that the mechanical envelope accommodates the connector length and that the operating environment aligns with the material specifications of the 450 series family.

Headers, Male Pins Part Context

This component is part of the Mill-Max 450 series, which specializes in high-reliability precision-machined interconnects. The manufacturer has been producing such components since 1971. This specific model represents a standard grid-based header solution within their extensive portfolio of board-to-board and wire housing products.

Headers, Male Pins Replacement Considerations

Cross-reference with other 450-series variants from Mill-Max for different row counts or termination styles. Verify compatibility with Preci-Dip equivalents if sourcing from alternative distributors, ensuring identical pin count, pitch, and mechanical dimensions are maintained.
