450-40-218-00-001000

$14.98

Description：CONN HEADER VERT 18POS 2.54MM
Series：450
Mfr：Mill-Max Manufacturing Corp.
Package：Tube

SKU:c3f2d2f5036b Category: Headers, Male Pins Brand: Mill-Max Manufacturing Corp.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

450-40-218-00-001000 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Mill-Max Manufacturing Corp.. Its product description is CONN HEADER VERT 18POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 450-40-218-00-001000

Description：CONN HEADER VERT 18POS 2.54MM
Series：450
Mfr：Mill-Max Manufacturing Corp.
Package：Tube
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：18
Number of Rows：2
Row Spacing - Mating：0.100" (2.54mm)
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.166" (4.22mm)
Contact Length - Post：0.156" (3.96mm)
Overall Contact Length：0.477" (12.12mm)
Insulation Height：0.110" (2.79mm)
Contact Shape：Circular
Contact Finish - Mating：Tin
Contact Finish Thickness - Mating：200.0µin (5.08µm)
Contact Finish - Post：Tin
Contact Material：Brass Alloy
Insulation Material：Polycyclohexylenedimethylene Terephthalate (PCT)
Features：-
Operating Temperature：-
Ingress Protection：-
Material Flammability Rating：-
Insulation Color：Black
Current Rating (Amps)：-
Voltage Rating：-

Headers, Male Pins datasheet and documents for 450-40-218-00-001000

450-40-218-00-001000

Headers, Male Pins Overview

The Mill-Max 450-40-218-00-001000 is a rectangular header connector featuring 18 positions arranged in a single row. It utilizes through-hole mounting for secure board attachment and operates with a 0.100 inch (2.54mm) contact spacing. The component includes a push-pull fastening mechanism to ensure stable connection integrity during operation.

Headers, Male Pins Feature Summary

Features a push-pull fastening mechanism for secure retention
Designed for reliable board-to-board interconnections
Utilizes through-hole termination for robust mounting

Headers, Male Pins Applications

Board-to-board electronic connections
General interconnect applications requiring secure retention

Headers, Male Pins Procurement Notes

Verify the specific manufacturer datasheet to confirm current RoHS compliance status and detailed environmental certifications. Ensure that the required contact materials and plating specifications align with your design requirements before finalizing procurement decisions.

Headers, Male Pins Selection Notes

Select this component when a 18-position header with through-hole termination is required. The 0.100 inch pitch supports standard digital signal routing. The push-pull feature provides mechanical stability superior to standard press-fit headers in vibration-prone environments.

Headers, Male Pins Part Context

This part belongs to the Mill-Max 450 series of rectangular headers. These connectors are engineered for high-density interconnects where space efficiency and reliable electrical performance are critical. The series offers various position counts to accommodate diverse circuit board layouts.
