6052580

Overview

The SICK V2D611P-MMSCI4 (Order No. 6052580) is a programmable 2D image sensor utilizing CMOS global-shutter technology with manual optical focus. It features an integrated dual-color LED illumination system emitting at 617 nm and 470 nm, supplemented by green feedback and red auxiliary adjustment LEDs. The device supports application software including Nova Inspector with Quality Inspection License and optional Intelligent Inspection Upgrade via HALCON API. Operating within a working area of 50 mm to 300 mm using internal lighting, it complies with Laser Class 1 standards per 21 CFR 1040.10.

Feature Summary

• Programmable 2D imaging with CMOS global-shutter sensor technology
• Integrated dual-wavelength visible LED illumination for versatile inspection tasks
• Supports advanced algorithmic tools through HALCON API integration
• Includes factory calibration and adjustable optical focus mechanism

Applications

• Automated quality inspection in manufacturing environments
• Precision component verification using intelligent inspection algorithms
• Machine vision systems requiring programmable 2D snapshot capabilities

Procurement Notes

Verify the specific order number 6052580 against official SICK documentation to confirm inclusion of the Quality Inspection License and HALCON compatibility. Ensure the required software licenses are valid for the intended application scope. Confirm that the integrated laser classification meets local safety regulations for your installation site.

Selection Notes

Select this model when programmable 2D imaging with integrated illumination is required. It is suitable for applications needing manual focus adjustment and support for third-party algorithm libraries like HALCON. Consider the working distance limitations imposed by the internal lighting configuration when designing the optical setup.

Part Context

This unit belongs to the SICK V2D series of 2D image sensors designed for industrial machine vision. These sensors combine hardware flexibility with software-defined functionality, allowing users to tailor inspection processes through licensed software upgrades rather than hardware changes.

Replacement Considerations

Consult SICK technical documentation for direct cross-references. Verify compatibility of software licenses and mounting interfaces if substituting with other models in the V2D family or newer generations.

FAQ

What software licenses are included with this part?

The device includes Nova Inspector with a Quality Inspection License. An optional Intelligent Inspection Upgrade License is available for enhanced tool usage.

Is the lens focus adjustable?

Yes, the sensor features manually adjustable optical focus to accommodate different working distances and field-of-view requirements.
