7N24570001

$14.79

Description：XTAL OSC TCXO 24.5760MHZ CMOS
Series：7N
Mfr：TXC CORPORATION
Package：Tape & Reel (TR),Tape & Reel (TR),Cut Tape (CT)

SKU:604be986f5d2 Category: Oscillators Brand: TXC CORPORATION

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

7N24570001 is listed in the Oscillators range at ChipApex. The manufacturer field lists TXC CORPORATION. Its product description is XTAL OSC TCXO 24.5760MHZ CMOS. Review the specifications below when checking this part for your BOM.

Oscillators specifications for 7N24570001

Description：XTAL OSC TCXO 24.5760MHZ CMOS
Series：7N
Mfr：TXC CORPORATION
Package：Tape & Reel (TR),Tape & Reel (TR),Cut Tape (CT)
Base Resonator：Crystal
Type：TCXO
Frequency：24.576 MHz
Function：Enable/Disable
Output：CMOS
Voltage - Supply：-
Frequency Stability：-
Absolute Pull Range (APR)：-
Operating Temperature：-40°C ~ 85°C
Spread Spectrum Bandwidth：-
Current - Supply (Max)：10mA
Ratings：-
Mounting Type：-
Package / Case：4-SMD, No Lead
Size / Dimension：0.276" L x 0.197" W (7.00mm x 5.00mm)
Height - Seated (Max)：0.079" (2.00mm)
Supplier Device Package：-

Oscillators datasheet and documents for 7N24570001

7N24570001

Oscillators Overview

The 7N24570001 is a temperature-compensated crystal oscillator (TCXO) manufactured by TXC Corporation. It operates at a nominal frequency of 24.576 MHz and utilizes CMOS output logic. The component features an enable/disable control function for power management. It is housed in a compact 4-SMD, no-lead package suitable for surface-mount assembly. Maximum supply current is specified at 10 mA. The base resonator technology is crystal-based, providing stable timing performance across operating conditions.

Oscillators Feature Summary

Integrated temperature compensation for frequency stability
CMOS output signal compatibility
Hardware enable and disable control capability

Oscillators Applications

Electronic timing circuits requiring precise clock signals
Industrial applications needing stable oscillation
Embedded systems utilizing CMOS-compatible interfaces

Oscillators Procurement Notes

Verify the specific voltage rating and load capacitance requirements against your system design before procurement. Confirm that the enable pin logic levels match your controller outputs. Check for any recent product discontinuance notifications from the manufacturer to ensure long-term availability for production runs.

Oscillators Selection Notes

Select this component when a stable 24.576 MHz clock source with low power consumption is required. Ensure the PCB layout supports the 4-SMD footprint dimensions. Consider the thermal environment, as TCXOs rely on temperature sensing for compensation accuracy within their specified operating range.

Oscillators Part Context

This part belongs to the TXC oscillator family, specifically designed for applications demanding high frequency stability without the complexity of external compensation networks. It serves as a direct replacement for standard crystals in designs requiring improved drift performance over temperature variations.
