801-87-004-10-132101

Headers, Receptacles, Female Sockets Overview

The Preci-Dip 801-87-004-10-132101 is an 8-position Single In-Line (SIL) socket connector designed for surface mount technology. It features a 2.54 mm pitch and right-angle termination for efficient PCB layout. The contacts are constructed from beryllium copper with gold plating on the mating interface, ensuring reliable conductivity. Rated for 3A current and 100V AC / 150V DC voltage, it operates within a temperature range of -55°C to 125°C. The housing utilizes glass-filled PCT material rated UL94 V-0.

Headers, Receptacles, Female Sockets Feature Summary

• Surface mount right-angle design for compact board integration
• Gold-plated beryllium copper contacts for corrosion resistance
• High-temperature resistant UL94 V-0 insulating material

Headers, Receptacles, Female Sockets Applications

• Industrial control system interconnections
• Consumer electronics internal circuitry
• Automotive electronic module connections

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific ordering suffix against official Preci-Dip documentation to confirm contact plating thickness and terminal finish specifications. Ensure the selected variant matches the required surface mount orientation and pin count. Cross-reference the manufacturer part number with authorized distributor catalogs to validate current availability status and compliance certifications prior to procurement.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a low-profile, right-angle SIL socket is required for surface mounting. The 2.54 mm pitch ensures compatibility with standard header pins. Consider the 3A current rating and high-temperature tolerance for applications involving moderate power loads or elevated thermal environments. Verify that the surface mount footprint aligns with the PCB design constraints.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the Preci-Dip 801 series of single in-line connectors. The series offers various configurations including through-hole and surface mount options with different pin counts. The 801-87 designation specifically indicates a socket variant with right-angle termination suitable for surface assembly, providing a robust connection solution within the broader rectangular connector family.

Headers, Receptacles, Female Sockets Replacement Considerations

Compatible substitutes include other 8-position, 2.54 mm pitch SIL sockets with surface mount right-angle termination. Verify mechanical dimensions, contact material, and plating specifications to ensure functional equivalence. Check for identical voltage and current ratings to maintain circuit integrity.
