852-90-042-10-001000

Headers, Male Pins Overview

The Mill-Max 852-90-042-10-001000 is a board-to-board connector header featuring 42 positions arranged in two rows. It utilizes a 0.050-inch (1.27mm) pitch and employs through-hole termination for secure PCB mounting. The contacts are designed as male pins with a tin plating finish to ensure reliable electrical conductivity. This unshrouded component incorporates a push-pull fastening mechanism, facilitating efficient mating and demating processes during assembly.

Headers, Male Pins Feature Summary

• Dual-row configuration supporting high-density interconnect applications
• Push-pull fastening system for simplified mechanical engagement
• Tin-plated male pin contacts for consistent signal transmission

Headers, Male Pins Applications

• High-density board-to-board interconnections
• Industrial control module assemblies
• Telecommunications equipment backplanes

Headers, Male Pins Procurement Notes

Verify the specific contact plating material and row count against the official Mill-Max datasheet prior to ordering. Confirm that the push-pull retention style aligns with the mechanical constraints of the target enclosure design. Ensure the through-hole footprint matches the printed circuit board layout specifications exactly to prevent installation errors.

Headers, Male Pins Selection Notes

Select this component when a dual-row, unshrouded header with a 1.27mm pitch is required. The push-pull feature is essential for applications demanding rapid assembly or frequent maintenance access. Verify that the tin plating meets the environmental and corrosion resistance requirements of the intended operating environment compared to gold alternatives.

Headers, Male Pins Part Context

This part belongs to the Mill-Max 852 series of precision machined interconnect components. The series specializes in high-reliability solutions for demanding electronic environments. As a manufacturer of custom and standard interconnects, Mill-Max focuses on maintaining strict quality controls for these board-to-board connection systems.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 42-position count, dual-row arrangement, 1.27mm pitch, and push-pull fastening mechanism. Verify compatibility of the tin-plated contact finish and through-hole termination style with existing manufacturing processes.
