929834-05-28-RK

Headers, Male Pins Overview

The 3M 929834-05-28-RK is a vertical pin strip header connector from the 929 series, designed for board-to-board applications. It features 28 positions with a single row and a 0.100-inch (2.54mm) pitch. The connector utilizes through-hole termination for soldering to printed circuit boards. Contact materials consist of copper alloy with tin plating on both mating and tail sections. The insulator is made of black PCT material rated UL94 V-0, supporting an operating temperature range of -40°C to 105°C and a current rating of 2.5A.

Headers, Male Pins Feature Summary

• Vertical pin strip design with breakaway capability for flexible prototype customization
• Solder tail construction facilitates wave soldering production processes
• Tin-plated copper alloy contacts ensure reliable electrical connectivity
• PCT insulator provides thermal stability and UL94 V-0 flammability rating

Headers, Male Pins Applications

• Board-to-board interconnections
• Prototype development and testing
• Industrial automation systems

Headers, Male Pins Procurement Notes

Verify component authenticity and datasheet alignment before integration. Confirm that the specific part number matches the required pin count and pitch specifications. Check for RoHS compliance status relative to project requirements. Ensure storage conditions maintain integrity of the tin-plated contacts. Validate mechanical fit within the intended PCB layout constraints.

Headers, Male Pins Selection Notes

Select this connector when a vertical, single-row header with 2.54mm pitch is required. Consider the breakaway feature if custom lengths are needed. Evaluate the 2.5A current rating against circuit demands. Ensure compatibility with mating socket connectors in the assembly. Verify through-hole mounting suitability for the target PCB manufacturing process.

Headers, Male Pins Part Context

This component belongs to the 3M 929 series of pin strip connectors. The series offers various configurations including horizontal and vertical orientations. These connectors are engineered for general-purpose electronic interconnects. The 929834 base model indicates a specific header variant within the broader product family.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Cross-reference with other 3M 929 series headers for similar mechanical dimensions. Verify electrical parameters match before considering alternative suppliers.
