929838-04-23

$4.19

Description：CONN HEADER R/A 46POS 2.54MM
Series：929
Mfr：3M
Package：Bulk

SKU:4bfbb23717c0 Category: Headers, Male Pins Brand: 3M

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

929838-04-23 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists 3M. Its product description is CONN HEADER R/A 46POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 929838-04-23

Description：CONN HEADER R/A 46POS 2.54MM
Series：929
Mfr：3M
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：46
Number of Rows：2
Row Spacing - Mating：0.100" (2.54mm)
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Through Hole, Right Angle
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.235" (5.97mm)
Contact Length - Post：0.145" (3.68mm)
Overall Contact Length：-
Insulation Height：0.215" (5.45mm)
Contact Shape：Square
Contact Finish - Mating：Tin-Lead
Contact Finish Thickness - Mating：100.0µin (2.54µm)
Contact Finish - Post：-
Contact Material：Copper Alloy
Insulation Material：Polybutylene Terephthalate (PBT), Polyester, Glass Filled
Features：-
Operating Temperature：-40°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：2.5A
Voltage Rating：-

Headers, Male Pins datasheet and documents for 929838-04-23

929838-04-23

Headers, Male Pins Overview

The 3M 929838-04-23 is a rectangular header connector from the 929 series, designed for board-to-board applications. It features a right-angle through-hole mounting style with 46 positions arranged in two rows. The connector utilizes a 0.100-inch (2.54mm) pitch and square-shaped male pins. Constructed with copper alloy contacts and black PBT insulation reinforced with glass fiber, it supports solder termination. The component operates within a temperature range of -40°C to 105°C and meets UL94 V-0 flammability standards.

Headers, Male Pins Feature Summary

Right-angle design facilitates compact board-to-board interconnections
Push-pull locking mechanism ensures secure mating stability
High-temperature resistant PBT insulation supports wave or infrared soldering processes

Headers, Male Pins Applications

Board-to-board electronic connections
Industrial automation systems
Data center infrastructure hardware

Headers, Male Pins Procurement Notes

Verify component authenticity against official 3M documentation due to potential supply chain variations. Confirm that the specific suffix matches the required pin count and orientation. Check RoHS compliance status as older batches may not meet current environmental regulations. Ensure storage conditions prevent moisture damage prior to soldering.

Headers, Male Pins Selection Notes

Select this model when a right-angle, high-density connection is required for industrial environments. The 46-position configuration suits complex circuit boards needing robust signal integrity. Consider the push-pull feature for applications requiring frequent maintenance access. Verify thermal ratings align with the operational environment constraints.

Headers, Male Pins Part Context

This component belongs to the 3M 929 series of headers and male pins. The series offers versatile options including single and double row configurations with various plating choices like gold, matte tin, or tin-lead. These connectors are engineered for durability in demanding electronic assemblies, providing reliable performance across diverse industrial sectors.
